101AV Professional Security Monitor 21.5″ 5MP Super HD-TVI, AHD, CVI & CVBS 16:9, 1 HDMI & 2 BNC Inputs and Outputs, Working with Super HD 5MP Security Cameras Directly in Addition to DVR/NVR & PC

Price: $198.00
(as of Mar 02, 2025 21:44:04 UTC – Details)

Product Description

This is a brand new high performance 21.5-inch LED/LCD video monitor specifically designed for security Industry. It displays high quality video or computer signals via multiple inputs. Its features include one HDMI, two BNC input, and two looping BNC output. Certified by CE, FCC-DOC and RoHS. Additional features include multi-language OSD (On-Screen Display).

Feature:

Ultra fine pixel pitch for close viewing in surveillance applicationsThe newest high definition, HD-TVI, HD-AHD, and HD-CVI, cameras will look crisp and lifelike. HD-TVI/AHD up to 5MP (2592×1440), HD-CVI up to 4MP (2560×1440), and CVBS up to 1000TVL.Existing and new HD surveillance system compatibility with multiple video formats including new full high definition HD-TVI/HD-AHD/HD-CVI and traditional standard definition 960H/composite video cameras(can connect with analog HD/SD camera directly).Multiple inputs allow multi-device setups without the need to juggle cordsFast 5 ms response time to avoid blurred motion monitoring and feed delays on critical momentAuto display recovery after power interruptionsGreat reliability rating 24/7 security application requirementsWide view angle of 178 degrees for fewer restrictions on your range of visionDesktop stand and standard VESA wall mount holes for desktop and wall mount installationsErgonomic tilt and swivel design for a more efficient, productive, and safer workplaceUser friendly front push button operation

Ultra fine pixel pitch for close viewing in surveillance applicationsAuto display recovery after power interruptions Great reliability rating 24/7 security application requirements Wide view angle of 178 degrees for fewer restrictions on your range of vision

The newest high definition, HD TVI and AHD, cameras will look crisp and lifelike (need a TVI/AHD to HDMI converter) Existing and new HD surveillance system compatibility with multiple video formats including new full high definition HD TVI/AHD (need a TVI/AHD to HDMI converter)and traditional standard definition 960H/composite video cameras(can connect with analog CVBS camera directly).

Fast 5 ms response time to avoid blurred motion monitoring and feed delays on critical moment

Video Interface: 2 x BNC Composite In => Can connect to camera directly1 x BNC Composite out => Can connect to another monitor1 x VGA1 x HDMI Audio Interface: 1 x PC Audio; Power Interface: 1 x DC in

Specification:

Model No.: MT-G3D215HD

Size: 21.5″ Wide Screen

Brightness: 250cd/m2

Contrast Ratio: 1000:1

Response Time: 5 ms

Colors: 16.7M

Viewing Angle: H:178°/V:178°

Video Inputs: 2 x HD Analog (BNC Connector) (TVI/AHD/CVI/CVBS), 1x HDMI

Video Outputs: 2 x HD Analog (BNC Connector) (TVI/AHD/CVI/CVBS)

HDMI Format: 4MP/2560×1440@30/60, 2MP/19201080@25/30/50/60HZ, 1600×1200@60HZ, 1440×900@60HZ, 1366×768@60HZ, 1280×1024@60HZ, 1280×720@60HZ, 1024×768@60HZ, 800×600@60HZ

Analog HD:

TVI: 5MP/2592×1944@20fps, 4MP/2560×1440@25/30fps, 2MP/1920x1080P@25/30fps, 1MP/1280x720P@25/30fps

AHD: 5MP/2592×1944@20fps , 4MP/2560×1440@25/30fps, 2MP/1920x1080P@25/30fps, 1MP/1280x720P@25/30fps

CVI: 4MP/2560×1440@25/30fps, 2MP/1920x1080P@25/30fps, 1MP/1280x720P@25/30/50/60fps

Power Consumption: 12VDC, 3A, <21W

VESA Size: 100x100mm

Auto Adjustment: Yes

OSD Menu: Yes

OSD Language: English, Spanish, German, Russian, Italian and French

Working Temperature: 0 ~ 40℃

Work Humidity: 5% – 90%

Packing Dimensions (LxDxW): 22.8″ x 4.7″ x 17″

Net Weight: 9.9 lbs

Certification: FCC-DOC , CE, and RoHS

What is in the box?

21.5″ HD LED Security Monitor x 1; Power Cord, Adapter, Stand, User’s Guide, HDMI Cable

#CCTV monitor, Security monitor, Security displays, BNC monitor, VGA monitor, Security screen, Security camera monitor, Analog monitor, DVR monitor, NVR monitor, CCTV camera monitor, Remote viewing monitor, Access control monitor, Alarm monitor, Monitoring monitor.

Add to Cart

Add to Cart

Customer Reviews

4.4 out of 5 stars 35

3.8 out of 5 stars 9

4.2 out of 5 stars 5

4.2 out of 5 stars 5

4.0 out of 5 stars 19

5.0 out of 5 stars 2

Price

$198.00$198.00 $175.00$175.00
—
—
—
—

Size
21.5 inch 19.5 inch 19.5 inch 21.5 inch 12″~23″ 23″-65″

Aspect Ratio
16:9 16:9 16:9 16:9 Hold up to 33lb (15Kg) Hold up to 88 lbs (40Kg)

Contract Ratio
1000:1 3000:1 3000:1 1000:1 VESA Size: 50x50mm, 75x75mm, 100x100mm VESA Size: Up to 600mm (W) x 400mm (H)

Response Time
5ms 5ms 5ms 5ms 20 degress of Forward Tilt and -20degrees of Backward Tilt 15 degress of Forward Tilt and -15 degrees of Backward Tilt

BNC Composite In
2 2 1 1 180 degrees of Swivel 180 degrees of Swivel

BNC Composite Out
2 1 1 1

HDMI

✓

✓

✓

✓

VGA

✓

✓

✓

Comb Filter with De-interlace
3D 3D 2.5D 2.5D

Power
12VDC, 3A, <21W 12VDC, 3A, <20W 12VDC, 3A, <20W 12VDC, 3A, <25W

Professional Full Line Security Monitors

Test Monitor

1. 21.5″ Super HD 5MP/2592×1944 over Coax LED Security Monitor. 1 HDMI & 2 Super HD BNC Video Inputs. BNC video-in port works directly with the new Super HD security cameras without going through any DVR or converters. It will allow security cameras send clear video by using a single Coax cable to the HD monitor, and it can prevent fuzzy or unclear images between the camera, recorder, and monitor. And 2 BNC Video Outputs for Second Monitor. Comprehensive range of Super High Definition product line, including cameras, DVRs/NVRs, and Super HD monitors.
2. Keeps video looking its best by preventing blurry or pixelated images. Preserve original high video quality without artifacts, signal loss, or distortion caused by digital processing and compression through a Digital Video Recorder or Distributor.
3. Super HD 5MP security monitors with BNC inputs allows them to be connected directly to the new super HD up to 5MP/2592×1944 resolution cameras for the much clear and more accurate video feed. And it is 10 times higher than the Standard Definition (0.46MP/960H, 0.3MP/CVBS or VGA) BNC resolution from Normal CCTV/security monitors. Support up to 5MP/2592×1944 Super HD-TVI, HD-AHD, and 4MP HD-CVI.
4. One of the biggest advantages of using BNC connector for security cameras is that they allow you to install multiple viewing monitors in different rooms up to 1000ft away from the DVR and cameras. This is a great option for businesses and homes with large areas that need to be monitored in more than one location, as it allows you to keep an eye on everything from multiple locations.
5. Fast 5ms response time to avoid blurred motion monitoring and feed delays on critical moment. Auto display recovery after power interruptions. Construction-black plastic bezel and removable base. NTSC/PAL/SECAM auto detection; Certification: FCC-DOC , CE, and RoHS. Desktop stand and standard VESA wall mount holes for desktop and wall mount installations. Wide view angle of 178 degrees for fewer restrictions on your range of vision.
6. Design for professional surveillance/security applications, 24/7/365. Need help? Don’t hesitate to contact us by email. We’re here to assist you with any questions or issues.
